Crankshaft Position Sensor (PMS-CKP)

DS Code:1855
Ways: 02 | Technology: Inductive


CITROËN:9639999980
CITROËN:1920AV
Delphi:SS1074812B1
E-Klass:ESR4880
HELLA:6PU009163591
MAXAUTO:5825
MAXAUTO:080091
MTE:70563
PEUGEOT:1920AV
PEUGEOT:9639999980
SENSORAUTO:SRP9980P

Manufacturer	Model	Engine	Fuel	Year
Citroën	C3	1.4 4Cil 8v	Gasoline	02 >
Citroën	C3	1.6 4Cil 16v	Gasoline	02 > 05
Citroën	C4 Pallas	1.6 4Cil 16v	Gasoline	06 >
Citroën	C4	1.6 4Cil 16v	Flex	07 >
Citroën	C4	1.6 4Cil 16v	Gasoline	04 >
Citroën	Xsara	1.6 4Cil 16v	Gasoline	00 > 05
Peugeot	206	1.4 4Cil 8v	Gasoline	98 >
Peugeot	206	1.6 4Cil 16v	Gasoline	00 >
Peugeot	206	1.6 4Cil 16v	Hybrid - Gasoline/LPG	02 >
Peugeot	306	1.6 4Cil 8v	Gasoline	00 > 02
Peugeot	307	1.6 4Cil 16v	Flex	06 >
Peugeot	307	1.6 4Cil 16v	Gasoline	00 >

Details Crankshaft Position Sensor (PMS-CKP)

The crankshaft position sensor sends an electrical signal to the injection module that allows the synchronization of the system: injection timing, ignition advance, high out of gear, etc.

The crankshaft position sensor set is basically comprised of a spur gear or phonic wheel, permanent magnet, ferromagnetic core, coil, coil wires, braided shield, and sensor connector.

The sensor cable is entirely covered by a metal mesh referred to as braided shield. This mesh is linked to a grounding line and prevents electromagnetic interferences from disturbing the pulse pattern sent by the sensor.

Some crankshaft position sensors are found in the front part of the engine, in the pulley, and others are already assembled on the engine flywheel.
