Fuel Level Sensor

DS Code:2308
Full: 63 ± 4 ohms | Empty: 363 ± 4 ohms | Note: The 2301 and 2308 sensors, despite their identical application, are different parts and if the wrong purchase occurs, vehicle installation will not be possible. The original codes informed on the site must be strictly followed.


Bosch:F000TE105Z
Bosch:F000TE1515
FIAT:7084737
FIAT:51709965
FIAT:51720973
FIAT:51807830
INDEBRÁS:0111710PR
Marelli:MAM00752
TSA:T010116
VP:8059

Manufacturer	Model	Engine	Fuel	Year	Note
Fiat	Idea Adventure	1.8 4Cil 8v	Flex	07 > 10
Fiat	Idea	1.4 4Cil 8v	Flex	05 > 07	MPI
Fiat	Idea	1.4 4Cil 8v	Flex	06 > 10
Fiat	Idea	1.8 4Cil 8v	Flex	05 > 07	MPI
Fiat	Idea	1.8 4Cil 8v	Flex	06 > 10
Fiat	Palio	1.0 4Cil 16v	Gasoline	02 > 03	MPI
Fiat	Palio	1.0 4Cil 8v	Flex	05 > 09	MPI
Fiat	Palio	1.3 4Cil 16v	Gasoline	02 > 03	MPI
Fiat	Palio	1.3 4Cil 8v	Flex	03 > 05	MPI
Fiat	Palio	1.4 4Cil 8v	Flex	05 > 07	MPI
Fiat	Palio	1.6 4Cil 16v	Gasoline	02 > 03	MPI
Fiat	Palio	1.8 4Cil 8v	Flex	03 > 07	MPI
Fiat	Siena	1.0 4Cil 16v	Gasoline	02 > 03	MPI
Fiat	Siena	1.0 4Cil 8v	Flex	05 > 08	MPI
Fiat	Siena	1.3 4Cil 16v	Gasoline	02 > 03	MPI
Fiat	Siena	1.3 4Cil 8v	Gasoline	02 > 05	MPI
Fiat	Siena	1.4 4Cil 8v	Flex	05 > 07	MPI
Fiat	Siena	1.6 4Cil 16v	Gasoline	97 > 00	MPI
Fiat	Siena	1.6 4Cil 8v	Gasoline	99 > 00	MPI
Fiat	Siena	1.8 4Cil 8v	Flex	03 > 07	MPI

Details Fuel Level Sensor

Located next to the fuel module, the sensor is basically composed of a float fixed to an articulate rod that moves its sliding contact. It measures the amount of fuel existing in the tank and informs the Electronic Control Unit (ECU), which, on its turn, controls the position of the fuel gauge indicator on the vehicle’s dashboard. In Flex-fuel vehicles, the fuel level sensor has a very important additional function, as it helps identify the type of fuel existing in the tank.
