Fuel Level Sensor

DS Code:2323
Full: 38 ± 4 ohms | Empty: 283 ± 4 ohms | Note: Sensors 2317 and 2323, although their application is identical in (Astra 2.0 8v Flex, Vectra 2.0 8v Flex and Vectra 2.4 16v Flex), are different parts and if the wrong purchase occurs, vehicle installation will not be possible. The original codes informed on the site must be strictly followed.


Bosch:0580313171
Bosch:0580313169
GM:93297135
GM:93363263
GM:93317613
GM:93372174
GM:94737019
GM:93314037
GM:93317612
INDEBRÁS:0110080PR
TSA:T010085
VDO:221040069R
VDO:221040085R
VP:8064

Manufacturer	Model	Engine	Fuel	Year
GM	Astra	1.8 4Cil 8v	Ethanol	01 > 04
GM	Astra	2.0 4Cil 8v	Flex	04 > 11
GM	Vectra	2.0 4Cil 8v	Flex	07 > 10
GM	Vectra	2.4 4Cil 16v	Flex	06 > 09
GM	Zafira	2.0 4Cil 8v	Flex	04 > 10
GM	Zafira	2.0 4Cil 8v	Gasoline	01 >

Details Fuel Level Sensor

Located next to the fuel module, the sensor is basically composed of a float fixed to an articulate rod that moves its sliding contact. It measures the amount of fuel existing in the tank and informs the Electronic Control Unit (ECU), which, on its turn, controls the position of the fuel gauge indicator on the vehicle’s dashboard. In Flex-fuel vehicles, the fuel level sensor has a very important additional function, as it helps identify the type of fuel existing in the tank.
