Fuel Level Sensor

DS Code:23181
Full: 20 ± 4 ohms | Empty: 320 ± 4 ohms


Bosch:1582894193
Bosch:F000TE181J
RENAULT:0580314635
RENAULT:172025316R
RENAULT:0580200218
RENAULT:172022442R
RENAULT:250606171R
TSA:T010237
VP:8255

Manufacturer	Model	Engine	Fuel	Year
Renault	Logan	1.0 3Cil 12v	Flex	16 >
Renault	Logan	1.0 4Cil 16v	Flex	14 >
Renault	Logan	1.6 4Cil 16v	Flex	14 >
Renault	Logan	1.6 4Cil 8v	Flex	14 >
Renault	Logan	2.0 4Cil 16v	Flex	14 >
Renault	Sandero	1.0 3Cil 12v	Flex	16 >
Renault	Sandero	1.0 4Cil 16v	Flex	14 >
Renault	Sandero	1.6 4Cil 16v	Flex	14 >
Renault	Sandero	1.6 4Cil 8v	Flex	14 >
Renault	Sandero	2.0 4Cil 16v	Flex	14 >

Details Fuel Level Sensor

Located next to the fuel module, the sensor is basically composed of a float fixed to an articulate rod that moves its sliding contact. It measures the amount of fuel existing in the tank and informs the Electronic Control Unit (ECU), which, on its turn, controls the position of the fuel gauge indicator on the vehicle’s dashboard. In Flex-fuel vehicles, the fuel level sensor has a very important additional function, as it helps identify the type of fuel existing in the tank.
