Fuel Level Sensor

DS Code:2388
Full: 33 ± 4 ohms | Empty: 313 ± 4 ohms | System: TI Automotive | Technology: Resistive


RENAULT:8200616585
RENAULT:172029382R
RENAULT:6001550197
RENAULT:172027483R
RENAULT:MD213186RE
RENAULT:MD210949RE
TI Automotive:000102276AA
TSA:T010224
TSA:T010159
VP:8120
VP:8168

Manufacturer	Model	Engine	Fuel	Year	Note
Renault	Logan	1.0 4Cil 16v	Flex	07 > 14	D4D
Renault	Logan	1.6 4Cil 16v	Flex	07 > 14	K4M
Renault	Logan	1.6 4Cil 8v	Flex	07 > 14	K7M
Renault	Sandero	1.0 4Cil 16v	Flex	07 > 14	D4D
Renault	Sandero	1.6 4Cil 16v	Flex	07 > 14	K4M
Renault	Sandero	1.6 4Cil 8v	Flex	07 > 14	K7M

Details Fuel Level Sensor

Located next to the fuel module, the sensor is basically composed of a float fixed to an articulate rod that moves its sliding contact. It measures the amount of fuel existing in the tank and informs the Electronic Control Unit (ECU), which, on its turn, controls the position of the fuel gauge indicator on the vehicle’s dashboard. In Flex-fuel vehicles, the fuel level sensor has a very important additional function, as it helps identify the type of fuel existing in the tank.
