Manifold Absolute Pressure Sensor (MAP)

DS Code:1701

ALFA ROMEO:60811534
CITROËN:594607
CITROËN:594609
CITROËN:19204S
DAEWOO:7696064
DPL:888039
Delphi:SPD00169
E-Klass:ESM2169
FIAT:7696064
GAUSS:GI3069
GM:16137039
GM:12569240
GM:9389131
HOLDEN:8161370390
HOLDEN:16137039
HOLDEN:16017460
HYUNDAI:3933024750
KIA:0K95018211
LP:931169902
MAXAUTO:5180
MAXAUTO:02003
MTE:7120
OPEL:6238927
OPEL:1238788
OPEL:815701
PEUGEOT:19204S
PEUGEOT:594609
RENAULT:8933000153
RENAULT:7700706876
VOLVO:3411400
VOLVO:1378162
Manufacturer Model Engine Fuel Year Note
Daewoo Lanos 1.6 4Cil 16v Gasoline 97 > 02
GM Blazer 2.2 4Cil 8v Gasoline 95 > 97
GM Corsa 1.0 4Cil 16v Gasoline 96 > 02
GM Corsa 1.0 4Cil 8v Gasoline 94 > 02
GM Corsa 1.4 4Cil 8v Gasoline 94 > 96
GM Corsa 1.6 4Cil 16v Gasoline 95 > 01
GM Corsa 1.6 4Cil 8v Gasoline 95 > 06
GM Ipanema 1.8 4Cil 8v Ethanol 92 > 96
GM Ipanema 1.8 4Cil 8v Gasoline 92 > 96
GM Ipanema 2.0 4Cil 8v Ethanol 92 > 96
GM Kadett 1.8 4Cil 8v Ethanol 92 > 96
GM Kadett 1.8 4Cil 8v Gasoline 92 > 96
GM Kadett 2.0 4Cil 8v Ethanol 92 > 96
GM Kadett 2.0 4Cil 8v Gasoline 92 > 96
GM Monza 1.8 4Cil 8v Ethanol 91 > 96
GM Monza 1.8 4Cil 8v Gasoline 91 > 96
GM Monza 2.0 4Cil 8v Ethanol 91 > 96
GM Monza 2.0 4Cil 8v Gasoline 91 > 96
GM Omega 2.2 4Cil 8v Gasoline 95 > 98
GM Omega 3.8 V6 12v Gasoline 99 > 05 Australiano
GM S10 2.2 4Cil 8v Gasoline 95 > 97
GM Suprema 2.2 4Cil 8v Gasoline 95 > 98
GM Tigra 1.6 4Cil 16v Gasoline 98 > 99
Renault Megane 1.6 4Cil 8v Gasoline 98 > 99

Details Manifold Absolute Pressure Sensor (MAP)

The manifold absolute pressure sensor (MAP) informs the electronic control unit (ECU) the absolute pressure measured inside the intake manifold under the several operation conditions of the engine.

The value obtained is added to the information of air temperature. With these data, the system identifies the air mass that is being intake, calculates the progress of the ignition and the time for opening the injection nozzle, always looking for the ideal air/fuel ratio.

On older vehicles, the MAP sensor is fixed next to the engine and connected to the intake manifold through a hose.

In more modern vehicles, the MAP sensor is integrated and its function is to inform the pressure in the intake manifold and the temperature of the air. The sensor is directly fixed by screws on the intake manifold (it does not use a hose).
